NM 5002

Tube filling machine for plastic, laminate and aluminum tubes (500 ppm)

Basic Info

  • TECHNOLOGY: Tube Filling
  • INDUSTRY: Home Care, Personal Care, Food, Chemicals
  • SEGMENT: Other Home Care, Liquid Soaps, Cosmetics, Deodorants, Hair Care, Men's Shaving, Toothpaste, Skin & Sun Care, Oils & Fats, Sauces & Condiments, Spreads, Other Chemicals

Description

​Norden is well-known to provide the fastest tube filling machines in the world. This five-head filler is built for maximum output of your tube production. Several functions in the tube filler are servo driven, such as the filling pump and the lift at filling, etc. The machine is prepared for multi-color filling, also called co-extrusion filling, used for toothpaste applications.


Detailed Info

Footprint
Machine depth (mm)3800
Machine height (mm)2220
Machine length (mm)4300
Machine weight (kg)7000
Product range
Max filling volume (ml)200
Min filling volume (ml)1
Regulatory requirements
Food RegulationsCFR Title 21, 1935/2004/EC, 2023/2006/E
Safety RegulationsEN ISO 13732-1, 2009/105/EC, 94/9/EC, 97/23/EC, EN ISO 10218-2, EN ISO 11161, EN ISO 12100, EN ISO 13849-1, EN ISO 13849-2, EN ISO 13850, EN ISO 13855, EN ISO 13857, EN ISO 14119, EN ISO 14122 -1 -2 -3 -4, EN ISO 4414, EN ISO 7010, EN 349, EN 415-4, EN 547-1 -2 -3, EN 614-1 -2, EN 619, EN 953, IEC 60204-1, IEC 60529, IEC 60825-1, IEC/TS 62046, ISO/TR 14121-2, 2014/30/UE, 2006/42/EC, 2014/35/UE
Performance
Operating modeIntermittent
More Information
Other infoFilling & sealing plastic. Laminate tubes 19 to 38 mm tube diameter. 2 or 3 colors.
Packing range
Max pack diameter (mm)38
Min pack diameter (mm)10
Packaging range
Max pack length (mm)200
Min pack length (mm)50
Packaging features
Packaging materialAluminium - Laminated - Plastic
Packaging ShapeCylindrical - Oval
Value proposition
Value propositionPerformance
