NM 1703

Tube filling machine for tubes up to 65 mm diameter (170 ppm)

Basic Info

  • TECHNOLOGY: Tube Filling
  • INDUSTRY: Personal Care, Food
  • SEGMENT: Cosmetics, Deodorants, Hair Care, Men's Shaving, Skin & Sun Care, Liquid Soaps, Toothpaste, Other Food, Sauces & Condiments

Description

​A twin head machine for larger tubes, up to 65 mm in diameter. Sustainability is as important to us as it is to our customers! The improved Hot Air heating & sealing station is featuring an integrated heat exchange function. The state-of-the-art EasyWare control system offers you a superior overview of the machine operations and a streamlined information process.

Detailed Info

Footprint
Machine depth (mm)3350
Machine height (mm)2455
Machine length (mm)4950
Machine weight (kg)4800
Product range
Max filling volume (ml)450
Min filling volume (ml)1
Regulatory requirements
Food RegulationsCFR Title 21, 1935/2004/EC, 2023/2006/E
Safety RegulationsEN ISO 13732-1, 2009/105/EC, 94/9/EC, 97/23/EC, EN ISO 10218-2, EN ISO 11161, EN ISO 12100, EN ISO 13849-1, EN ISO 13849-2, EN ISO 13850, EN ISO 13855, EN ISO 13857, EN ISO 14119, EN ISO 14122 -1 -2 -3 -4, EN ISO 4414, EN ISO 7010, EN 349, EN 415-4, EN 547-1 -2 -3, EN 614-1 -2, EN 619, EN 953, IEC 60204-1, IEC 60529, IEC 60825-1, IEC/TS 62046, ISO/TR 14121-2, 2014/30/UE, 2006/42/EC, 2014/35/UE
Performance
Operating modeIntermittent
More Information
Other infoFilling tubes up to 65 mm dia at 170 tpm. Improved HA. Energy efficient.
Packing range
Max pack diameter (mm)65
Min pack diameter (mm)10
Packaging range
Max pack length (mm)250
Min pack length (mm)50
Packaging features
Packaging materialAluminium - Laminated - Plastic
Packaging ShapeCylindrical - Oval
Value proposition
Value propositionPerformance
